Commercial Steel Overhead Doors

ENERGY SERIES WITH INTELLICORE®

Polyurethane Insulated Commercial Steel Doors, R-values to 27.2

windcode icon

Clopay’s Intellicore overhead doors meet the needs of commercial buildings that require exceptional climate control. They feature polyurethane insulation which helps keep the building’s interior cooler in summer and warmer in winter.

Our energy-efficient commercial doors include stucco or woodgrain embossed steel exteriors with flush, minor ribbed, or raised panel section designs. Ideal applications include warehouses, manufacturing plants, municipal buildings and retail stores.

Glass/Window Options:

24″ x 8″
(3715, 3717, 3718, 3720, 3724, 3730)

24″ x 12″
(3715, 3717, 3718, 3720, 3724, 3730)

FULL-VIEW*
(3715, 3717, 3718, 3720, 3722, 3724)

19-1/2″ x 12″
(3721, 3723)

*Intellicore® polyurethane option available in models 3720, 3722, & 3724

Glazing Material Options:

CLEAR GLASS

GRAY TINTED GLASS

BRONZE TINTED GLASS

MIRRORED GLASS*

COLOR OPTIONS:

ALUMINUM PANEL COLOR MATCH

OBSCURE GLASS

WHITE LAMINATE GLASS*

FROSTED GLASS OR ACRYLIC

CLEAR ACRYLIC

*Mirrored and laminate not available in 1/2″

GRAY ACRYLIC

WHITE ACRYLIC

CLEAR POLYCARBONATE

BRONZE POLYCARBONATE

Glass thickness available in 1/8″, 1/4″ and 1/2″. Tri-wall polycarbonate thickness available in 1/2″. Low-E available on insulated glass.

STANDARD WHITE

ALMOND

DESERT TAN

BRONZE

Chocolate BROWN

SANDTONE

GRAY

CHARCOAL

CHOCOLATE

BLACK

TRINAR® WHITE

Premium finishing options include:

  • Custom Colors with Color Blast ® Garage Door Paint System
  • Bronze, dark bronze, black or custom color anodized finishing available on full-view sections only.

Performance Options Available:

Double-end hinge

3” Track

High performance hardware features 10 gauge end hinges, heavy-duty top bracket and 3″ sealed roller with 5/8″ stem.

Designed to counterbalance even the largest doors, commercial torsion spring assemblies can be designed for industry standard 10,000 cycles or can be upgraded to 25,000, 50,000 or 100,000 expected life cycles. Click here for details.

windcode icon

WindCode® reinforcement available up to W8 design pressure (DP) 52 PSF, depending on door configuration. Doors tested 50% greater than DP.

Upgrade your standard door with industrial-grade components.

Specialty Options Available:

Mullions

Carry-away, roll-away or swing-up mullions are available on select sizes.

Break-Away Section

Single section and double sections available on select sizes.

Pass Door

32″ wide x 80″ high, max 16’2″ wide section. Available in 2″ thick doors only.

Safe-T-Stop™ Chain Hoist

The Safe-T-Stop is a controlled descent sectional door hand hoist with an integral braking system allowing users to operate the door with confidence.

Construction

ENERGY SERIES WITH INTELLICORE®

ModelThicknessEmbossExterior SteelPatternR-Value*Std Max Width**Std Max Height
37303″Stucco27 GaugeMinor RibbedIntellicore Icon27.230’2″20’0″
37242″Stucco24 GaugeMinor Ribbed18.436’2″20’0″
37232″Woodgrain27 GaugeRaised Panel18.424’2″18’0″
37222″Stucco20 GaugeFlush18.432’2″20’0″
37212″Woodgrain27 GaugeFlush18.424’2″18’0″
37202″Stucco27 GaugeMinor Ribbed18.440’2″20’0″
37171 3/4″Stucco27 GaugeMinor Ribbed16.224’2″20’0″
37181 3/4″Stucco27 GaugeFlush16.224’2″20’0″
37151 3/8″Stucco27 GaugeMinor Ribbed12.918’2″16’0″

*Calculated door section R-value is in accordance with DASMA TDS-163
**For sizes over 32’2″ wide consult factory for specific configuration requirements.
